5kW Solar Battery Price in Pakistan

There is a problem buried inside this search term, and it costs people money.

“5kW solar battery” describes two completely different things depending on who is saying it. Sometimes it means a battery for a 5KW inverter. Sometimes it means a battery holding 5 kilowatt hours. Those are not the same specification, and a battery that satisfies one can fail badly at the other.

Sellers rarely clarify which one they are quoting. Buyers rarely know to ask. So somebody ends up with a pack that has plenty of stored energy but cuts out the moment the AC and the water pump start together, and nobody can work out why.

This guide separates the two questions, works through what a 5KW system in Pakistan actually needs, and gives you the numbers to size your own bank. No prices, because they move with the exchange rate. WhatsApp us now for the latest price of the battery at 03192070022 for the current rate on any configuration.

kW and kWh are not the same measurement

Worth getting straight, because everything else follows from it.

A kilowatt is a rate. It is how fast energy moves at a given instant. Your inverter is rated in kW because that is the maximum load it can supply at any one moment.

A kilowatt hour is a quantity. It is how much energy is stored or consumed over time. Your battery capacity and your electricity bill are both measured in kWh.

The plumbing comparison is imperfect but it lands. Kilowatts are how wide the pipe is. Kilowatt hours are how much water is in the tank. A wide pipe on a small tank empties fast. A narrow pipe on a big tank cannot fill your bath quickly no matter how much water you own.

So when someone says “5kW battery,” ask which they mean. If they cannot answer, that tells you something.

What a 5KW inverter demands from a battery

Start with the power side, because this is where most mismatches happen.

A 5KW hybrid inverter can deliver 5000 watts to your house. To do that, it has to pull that energy out of the battery, and at 51.2V nominal the arithmetic is straightforward.

5000W ÷ 51.2V = roughly 98 amps.

Factor in conversion losses of ten percent or so and the real draw is closer to 105 to 110 amps at full output. That is what your battery has to supply continuously, not in a brief burst.

Now look at battery datasheets. Two packs can both say 48V 100Ah and be rated very differently for discharge. One is specified for 100A continuous. Another is specified for 50A. Both store the same energy. Only one can support a 5KW inverter running near its ceiling.

Put the 50A pack behind that inverter and the BMS will disconnect under heavy load. The battery is not defective. It is protecting itself from a discharge rate nobody specified it for. But your lights go out mid evening and the inverter throws an error, and most people blame the inverter.

So the first rule for a 5KW system: the pack’s continuous discharge rating must cover your peak draw, not your average one. Ask for that figure in amps, and ask for the peak rating with its permitted duration, which is what handles motor and compressor startup surges.

Our detailed guide to the 48V 100Ah lithium battery covers discharge ratings and parallel stacking in more depth.

Now the energy side: how many kWh do you need?

This is the question that decides how long your backup lasts, and the honest answer is that it depends entirely on your house, not on your inverter.

A 5KW inverter can be paired with 5 kWh of storage or 20 kWh. Both work. One gives you a short evening, the other gets you through the night with the AC running.

Work it out properly. List what you want running when the grid is down, and for how many hours.

A DC inverter ceiling fan draws around 75W. An older AC fan is closer to 100W. LED lights run 10 to 15W each. A modern inverter refrigerator averages 100 to 150W across a full day once you account for the compressor cycling. A 43 inch LED television is around 80W. Routers, chargers and small electronics across a household add up to roughly 50W. A 1.5 ton inverter air conditioner sits somewhere around 1000 to 1500W in steady operation, with a considerably higher draw at startup.

Multiply each item by its hours, add them up, then add about 15 percent for inverter conversion and wiring losses. Divide by 1000 for kilowatt hours.

Three common outcomes in Pakistani households:

A fans, lights, fridge and electronics evening of six hours usually lands between 3 and 5 kWh. One 48V 100Ah pack, which is 5.12 kWh nominal and about 4 kWh delivered after depth of discharge and losses, covers this.

The same load plus one inverter AC for three or four hours lands between 7 and 10 kWh. Two packs in parallel, or one larger unit.

A larger house running two ACs and a water pump overnight lands at 15 kWh or more. Three or four packs, or a 48V 314Ah class unit.

Notice that the inverter never changed. Only the storage did.

What a 5kW array actually generates here

Sizing the battery without knowing what will refill it is how people end up with a bank that never reaches full charge.

Pakistan has excellent irradiance by global standards. A well oriented 5kW array in most of the country produces somewhere in the region of 18 to 25 kWh on a clear summer day, and drops to roughly 10 to 15 kWh in late December when the days are short and the sun sits low. Dust on the panels, shading and high panel temperatures all shave off more than people expect, and panel efficiency falls as the cells get hotter, which is a genuine factor in June in Sindh and south Punjab.

Two things follow from that.

First, in summer a 5kW array comfortably generates more than a typical household consumes during daylight, so there is real surplus to store. That is what makes a battery worthwhile.

Second, in winter the same array may only just cover daytime consumption with little left over. A very large battery bank behind a 5kW array will not fully recharge on a short December day. A pack that never completes a full charge cycle ages faster than one that does, so oversizing storage relative to your generation is not a free decision.

As a working guide, storage roughly equal to half a day’s winter generation is usually rechargeable year round. Beyond that, expect some months where the bank cycles shallow.

The net metering change, and why storage moved up the list

For years the standard advice was to skip the battery. Export your surplus to the grid during the day, draw it back at night, settle monthly. Net metering did the storage for you and the meter kept score.

That calculation changed. The Economic Coordination Committee approved amendments to net metering regulations cutting the buyback rate to Rs 10 per unit, down from Rs 27, with the government stating that existing consumers would not be affected and the revised rate would apply to new ones.

The consequence for anyone installing now is simple. Exporting a unit earns you a fraction of what buying that unit back costs. Storing it and consuming it yourself in the evening captures the full retail value instead.

This is the whole reason battery questions moved from the end of the solar conversation to the middle of it. Pakistan installed panels at extraordinary speed, importing 22 gigawatts of them in 2024, close to half the entire installed national generating capacity of 46 GW, with solar reaching 24 percent of total generation by the first five months of 2025. The panels are there. The storage is what most of those systems are still missing.

Which battery type suits a 5KW system

Not every chemistry can support this class of inverter well.

Flooded lead acid struggles here. To supply 5000W at 48V from lead acid, you need a large bank, because you can only safely use about half its rated capacity and its discharge rate under heavy load causes significant voltage sag. You also get 300 to 500 useful cycles if you are disciplined about depth of discharge, which most households are not during a July load shedding stretch.

Tubular batteries handle deep cycling better than flat plate and are a reasonable budget path for a lightly loaded 5KW system. They are very heavy, they need water topping and ventilation, and they lose capacity in sustained heat.

Dry and AGM remove the maintenance but not the fundamental cycle life limitation, and they sulphate if left at partial charge for long stretches, which happens every winter when charging windows shorten.

Lithium iron phosphate is what most 5KW installations now use, and the reasons are specific rather than general. It delivers high continuous current without voltage sag, which is exactly what a 5KW inverter needs. It gives 80 to 90 percent usable depth of discharge instead of 50, so you need far less nominal capacity for the same real backup. It accepts charge quickly, which matters on a short winter day when your charging window is five hours rather than nine. And it runs several thousand cycles instead of several hundred.

The full chemistry comparison, including where tubular still makes sense, is in our guide to solar battery pricing in Pakistan.

Configurations that work

Here is how 5KW systems are typically built here.

A single 48V 100Ah pack gives 5.12 kWh nominal, roughly 4 kWh delivered. This suits a household running fans, lights, a fridge and electronics through an evening, with no air conditioning on backup. Confirm the pack is rated for at least 100A continuous or you will not be able to use the inverter’s full output.

Two 48V 100Ah packs in parallel give 10.24 kWh nominal, roughly 8 kWh delivered, and double the available discharge current. This is the most common upgrade and covers an evening with one inverter AC running for several hours.

A single 48V 314Ah unit gives around 16 kWh nominal. Fewer connections, fewer things to go wrong, and a single warranty. Suits larger homes and small commercial premises. It also needs an array and a charge window capable of refilling it.

If you are stacking packs in parallel, they should be the same model, the same capacity and close in age. Charge both to a similar state before connecting them and check their resting voltages are within about half a volt of each other. Run equal length cables from each pack to the busbar, because a pack on a shorter cable sits on a lower resistance path and carries more current on every cycle. Over years, that imbalance shows.

You can compare the units we stock, including 24V options for smaller systems, on the products page.

Getting the installation right

A few things that decide whether you are happy in year three.

Set the charge profile to lithium at commissioning, or configure it manually. For a sixteen cell LiFePO4 pack, absorption typically sits around 56.8 to 57.6V, float around 54.4 to 55.2V, and low voltage cutoff somewhere between 44 and 47V. Disable equalisation entirely, since that stage exists to stir lead acid electrolyte and does nothing for lithium except hold it at excessive voltage.

Check whether the BMS communicates with your inverter over CAN or RS485. LiFePO4 has a deliberately flat discharge curve, sitting near 52 to 53V through most of its usable range, so an inverter estimating state of charge from voltage alone is guessing. Communication is model specific, not brand specific, so give us your inverter model and firmware version and we will confirm rather than assume.

Site the pack somewhere shaded and ventilated. Cycle life ratings are measured near 25°C, and a sealed metal enclosure on a rooftop in Multan or Rahim Yar Khan in June is nowhere near that.

If you are in Quetta, Skardu, Ziarat or upper KP, specify low temperature charge protection. Charging LiFePO4 below 0°C causes permanent lithium plating on the anode. A properly protected pack refuses charge until it warms, which looks like a fault and is the battery doing its job.

Size your cables and breakers for the current, not the power. At 110 amps continuous, undersized lugs and loose terminal bolts generate heat, and heat at a connection is how connections fail.

What actually drives the price

Since the voltage and capacity on the sticker do not explain the spread between quotes, here is what does.

Cell grade dominates. Grade A cells are tested and matched for capacity and internal resistance before assembly. B grade and reclaimed cells drift apart in service, and once they drift the weakest cell caps the capacity of the whole pack. A battery built from unmatched cells can measure correctly on delivery and lose a serious share of usable capacity within a year.

BMS capability is next. Passive balancing bleeds high cells through a resistor. Active balancing moves charge between them. Add temperature sensing, low temperature protection and inverter communication and the board cost rises considerably.

Continuous discharge rating is a real cost difference, not a marketing one, and for a 5KW system it is the specification that determines whether the battery is fit for purpose at all.

Then warranty backing, whether replacement modules are stocked locally, and what is bundled into the number: delivery, cables, lugs, breakers, installation support and inverter configuration.

Because the exchange rate, cell costs, freight and seasonal demand all move independently, published prices go stale quickly. The full breakdown of those market forces is in our guide to the lithium battery price in Pakistan today.
